1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane

1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane

    • 1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane
    • 1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane
    • 1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane
    • 1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane
    • 1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane
  • 1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane

    Product Details:

    Place of Origin: China
    Brand Name: Fuhua
    Certification: ISO9001, ISO14001, ISO45001, CE
    Model Number: FH-TPO

    Payment & Shipping Terms:

    Minimum Order Quantity: 100 square meters
    Price: FOB Qingdao USD1.00-5.00/KG
    Packaging Details: Plastic Bag
    Delivery Time: 7 days after order confirmation
    Payment Terms: T/T, L/C, D/P, or others
    Supply Ability: 4 million square meters per month
    Contact Now
    Detailed Product Description
    Width: 1m, 2m, 2.05m, 3M, 4M Length: 20m
    Thickness: 1.0mm, 1.2mm, 1.5mm, 2.0mm Color: White, Grey
    Type: Homogeneous TPO Membrane, Reinforcement TPO Membrane, Self-adhesive TPO Membrane, TPO Membrane With Fabric, Useage: Building Waterproof Material
    Application: Roofs Tunnel Pool Basement Garbage Disposal Facilities Surface: Smooth, Embossed And Customized
    Material: TPO

    TPO waterproof membrane is a waterproof sheet, consisting of thermoplastic polyolefin compound resin materials as the base stock, also reinforced with fiber backing materials, and manufactured by advanced extrusion machining technology.
    1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane
    Specification:
    Thickness(mm) - 1mm, 1.2mm, 1.5mm, 1.8mm, 2.0mm
    Width(m) - 1/2/2.05
    Length(m/roll) - 10/15/20
    Color - Black, White or as customized
    1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane
    1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane

    Type:
    H type: Homogeneous TPO membrane
    L type: with fabric backing
    P type: reinforced with fiber
    1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane
    Charateristics:
    1. Easy installation and dimensional stability: Able to be wieldable under wide range of temperature and experience minus dimensional change in thermal treatment
    2. High tensile strength and elongation thus can accommodate movements of substrates
    3. Good flexibility under low temperature, good adaptability to ambient temperature difference
    4. Secure anti-puncture and good rooting resistance, no pollution caused to environment when being welded and good waterproofing choice for plant roofs.
    5. Good plasticity: Convenient and fast treatment of detailed parts of corners and edges
    6. 3 meters width reduces the joints and helps saving materials or labor cost.
            Specification

          H L   P   G GL

    The resin thickness of middle fabric, mm≥         0.40

    Maximum tension,N/cm≥   200   250     200

    Tension strength, Mpa≥ 12.0         12.0

    Maximum tension elongation,%≥       15

    Breaking elongation, %≥ 500 250       400 200

    Heat treatment size change rate,%≥ 2.0 1.0   0.5   0.1 0.1

    Low temperature bend   -40℃ No crack

      Impermeable   0.3Mpa, 2h. No seepage

    Attack resistance   0.5kg m, No seepage

    Static charge resistance       20KG, No seepage

    Seam strip strength,N/mm≥ 4.0ormembrane break     3.0

    Right-angel tear strength,N/mm≥ 60         60

    Trapezoid tear strength N≥ 300   450     350

    Water absorption(70℃ 168h)%≤     4.0

    Heat aging   Time     672h
    (115℃)
        Appearance No blister, flaw, delaminatio, coherence, hole

        Tensile strength retention,%≥     90

        Elongation rate of keeping,%≥     90

        Low temperature bend   -40℃, no crack

    Chemistry   Appearance No blister, flaw, delamination, coherence, hole
    resistance
        Tensile strength retention,%≥     90

        Elongation rate of keeping,%≥     90

        Low temperature bend   -40℃, no crack

    Artificial weather   Time     1500h
    accelerated aging
        Appearance No blister, flaw, lamination, coherence, hole

        Tensile strength retention,%≥     90

        Elongation rate of keeping,%≥     90

        Low temperature bend   -40℃, no crack

    1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane
    1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane
    Usage:
    Widely applied on various kinds of waterproofing projects:
    1. Subways and tunnels
    2. Roofs of sports complex
    3. Green roofs
    4. Exposed roofs
    5. Steel roofs
    6. Waste land filling yards
    1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane
    Packaging:
    Rolled with hard materials and packed with plastic bags or woven bags.
    1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane
    Our Services
    1.   Our warranty period is one year against the date of shipment.
    2.   Free samples of waterproof membranes are available for your closer checking.
    3.   Well trained and experienced sales person to help you with any of your questions.
    4.   Strong technical support.
    5.   We will handle with each piece of document which are necessary during export to abroad and try our best to provide any         special required document in destination customs. Such as the certificate of origin.

    1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane

    1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane

    1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane

    1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane

    1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane

    1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane

    1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane

    1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane

    1.2MM TPO(Thermoplastic Polyolefin) waterproof membrane, TPO waterproof membrane
