2019 hot sell swimming pool liner/pvc swimming pool liner/pvc pool liner material

Name: 2019 hot sell swimming pool liner/pvc swimming pool liner/pvc pool liner material
Brand: Fuhua
SKU: FH-PVC13
Price: 0.50 USD
Availability: InStock
Rating: 4.6 (142 reviews)

Brand Name:	Fuhua
Model Number:	FH-PVC13
MOQ:	100 square meters
Price:	FOB Qingdao USD0.50-5.00 per square meters
Payment Terms:	T/T, L/C, D/P, or others
Supply Ability:	4 million square meters per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001, ISO14001

Width:

1.83m, 2.0m, 2.05m

Roll Length:

20 Meters

Material:

PVC

Color:

Blue

Surface Treatment:

Smooth, Embossed Or Customized

Application:

Swimming Pool

Packaging Details:

Plastic Bag

Supply Ability:

4 million square meters per month

Product Description

PVC Waterproof Membrane is one kind of polymer waterproof with high quality, it is made from polyvinyl chloride resin, mixed with plasticizer, filler, antioxygen, ultraviolet absorber and other auxiliaries.

Specification
No.	Items			Technical Data
				H	L	P	G	GL
1	Upper Resin Thickness					≥0.40mm
2	Tensile Property	Max. Tension (N/cm)		-	≥120	≥250	-	≥120
		Tensile Strength (MPa)		≥10	-	-	≥10	-
		Elongation /Max. Tension		-	-	≥15%	-	-
		Breaking Elongation		≥200%	≥150%	-	≥200%	≥100%
3	Dimensional Changing when Heating			≤2.0%	≤1.0%	≤0.5%	≤0.1%	≤0.1%
4	Low Temperature Flexibility			-25℃, No cracking
5	Impermeability			0.3Mpa, 120 Minutes, No leaking
6	Shock Resistance			0.5kg·m, No leaking
7	Static Load Resistance			-	-	20kg, No leaking
8	Joint Peel Strength (N/mm)			≥4.0		≥3.0
9	Right-angled Tearing Strength (N/mm)			≥50	-	-	≥50	-
10	Trapezoid Tearing Strength (N)			-	≥150	≥250	-	≥220
11	Water Absorption Coefficient		After dipping	70℃, 168 hours, ≤4.0%
			After sun-cure	70℃, 168 hours, ≥-0.40%
12	Thermal Aging (80℃)	Time		672 hours
		Appearance		No bubbling, cracking, layering, cohering or holes
		Holding / Max. Tension		-	≥85%	≥85%	-	≥85%
		Tensile Strength Holding		≥85%	-	-	≥85%	-
		Elongation Holding / Max. Tension		-	-	≥80%	-	-
		Breaking Elongation Holding		≥80%	≥80%	-	≥80%	≥80%
		Low Temperature Flexibility		-20℃, No cracking
13	Chemical Resistance	Appearance		No bubbling, cracking, layering, cohering or holes
		Holding / Max. Tension		-	≥85%	≥85%	-	≥85%
		Tensile Strength Holding		≥85%	-	-	≥85%	-
		Elongation Holding / Max. Tension		-	-	≥80%	-	-
		Breaking Elongation Holding		≥80%	≥80%	-	≥80%	≥80%
		Low Temperature Flexibility		-20℃, No cracking
14	Artificial Weathering Aging	Time		1500 hours (single-ply roofing 2500 hours)
		Appearance		No bubbling, cracking, layering, cohering or holes
		Holding / Max. Tension		-	≥85%	≥85%	-	≥85%
		Tensile Strength Holding		≥85%	-	-	≥85%	-
		Elongation Holding / Max. Tension		-	-	≥80%	-	-
		Breaking Elongation Holding		≥80%	≥80%	-	≥80%	≥80%
		Low Temperature Flexibility		-20℃, No cracking

Product Features:

1) Long life, aging-resistant, roofing materials can be over 20 years, and if underground use it can be 50 years.

2) High tensile strength, high extensibility, small dimensional change when heat treatment.

3) Good flexibility under low temperature, good variability to be adaptable to temperature difference of the environment.

4) Good rootage penetration resistibility, suitable to be used for planted roof.

5) Good perforating resistibility.

6) Convenient for construction, weldable, firm and secure, environmental protective and pollution free.

7) Strong chemical resistance, adaptable to special situations.

8) Good plasticity, convenient and fast treatment on delicate parts of corners and edges.

9) Easy maintenance, low cost.

Application:

1) Roof construction and steel structure of both industrial and civil engineering.

2) Underground engineering, such as subways, tunnels, air Raid shelter, etc.

3) Other projects, for example, dam, water reservoir, artificial lake, roof for plant and others.

Storage and Transportation:

1) Separate storage for different models.

2) Temperature should be below 45℃.

3) Avoid direct sunshine, rain, keep ventilated.

Thickness: 1.2mm, 1.5mm, 2.0mm

Width: 2.05m, or customized width

Length: 20m, or customized width

Color: White, Green, Blue, or customized color
